GANTRY OF WORKSHOP

New product

Workshop gantry mounted on swivel wheels for the assembly or maintenance teams to realize lifting operations in internal service.

Useful maximum load: 1T

DOC PORTIQUE D'ATELIER

 DOC PORTIQUE D'ATELIER + VÉRINS

More details

To order - deadline 5-6 weeks

3 545,00 €

Add to wishlist

More info

DESCRIPTION

Workshop gantry mounted on swivel wheels for the assembly or maintenance teams to realize lifting operations in internal service.

The gantry can receive an electric hoist or manual

  • Movable load on smooth and clean ground
  • Adjustable in height by 100 mm (minimum 1970 mm and max 3070mm)
  • Useful maximum load: 1T
  • Reach: 2 310 mm
  • Weight: +/- 220 kg

DOMAINS OF USE

Our machines are designed for industrial exploitation.

  • Atmosphere without specific constraint.
  • Atmosphere with specific constraint for use in chemical environments, food or pharmaceutique.

ADVANTAGES

  • Disassembled into 3 or 5 parts for easy transportation by van (type trafic)
  • The simplified maintenance allows a reduced asset Job
  • Our equipment is delivered fully assembled, ready for operation, it is provided with plate manufacturer CE, technical documentation and the EC declaration of conformity.
  • Equipment meets the requirements to the Machinery Directive 2006/42 /CE
  • Mechanical and electrical elements to standard industry

CHARACTERISTICS

  • Manufacturing painted steel or stainless steel
  • Bearing in IPE iron
  • Swivel wheels with polyamide

Data sheet

Height3230 mm max
Width2500 mm
Depth1500 mm
Weight220 kg without option
UseIndustrial use less than 1000 H / year
Sound levelLess than 70 dB at 1m
General constructionPainted steel rust protection
Power supplyAccording to option
Total powerAccording to option
DocumentationTechnical file including manual handling, mounting and connection, use, maintenance, spare parts list, EC certificate
