ERIFUT 1 XNP LT DOSING View larger

ERIFUT 1 XNP LT DOSING

New product

The ERIFUT 1 XP LT DOSING allows the semi-automatic packaging in accordance with a target weight with a partial diving cane.

Machine sold with fill lance diameter 40 mm, stroke 900 mm stainless pneumatic actuator.

More details

To order - deadline 5-6 weeks

27 293,00 €

Add to wishlist

Accessories

More info

DESCRIPTION

The ERIFUT 1 XP LT DOSING allows the semi-automatic packaging in accordance with a target weight with a partial diving cane.

The ERIFUT 1 XP LT DOSING is ergonomically designed to optimize the conditions of handling and operator exposure in an improvement process complies with REACH requirements :

  • Control panel and deported maneuvering system
  • No direct contact with the dip tube
  • No direct exposure to the emanation or splashing (completely removed with an extractor hood)
  • No awkward handling of the dip tube

This configuration, associated with rollers conveyor, is ideal for the filling of foaming products in barrels or containers.

Filling is performed, based on a unit weight target, by an automatic filling cycle triggered by the operator

DOMAINS OF USE

Our machines are designed for industrial exploitation.

  • Atmosphere without specific constraint.
  • Atmosphere with specific constraint for use in chemical environments, food or pharmaceutique.For example: ISO 7 clean room or laboratory class D, GMP strain, ASM BPE, etc ..
  • Our machines can meet the requirements of the ATEX directive for use in explosive atmosphere Zone 1,21 and 2,22.

FEATURES

Motion control

  • The diving system (Z axis) ensures pneumatically diving the filling cane in the container.
  • Barreling adjustable arm height punctually with tools.

Management dosage packaging

  • Direct weighing dosing solution by packaging (in legal metrology or not)

Different weighing infrastructure are proposed according to your needs

  • Infrastructure in U type pallet weighs, weighing plate, infrastructure weighed conveyor free rollers, etc…

The base configuration includes:

  • The ERIFUT 1 XP LT with équipments :
  • Filling lance diam 40 stroke 900
  • Electrical control box
  • Pneumatic equipments
  • A weighing legal metrology with a stainless steel weighing plate 600x600 range 300 Kg / 100 g with rollers conveyor (type 800XL630 IRO) and a weight level indicator
  • The set is delivered fully assembled, ready for operation
  • Technical file including manual handling, mounting and connection, use, maintenance, spare parts list, EC certificate

ADVANTAGES

  • Economic solution
  • Improves conditions of handling and operator exposure in an improvement process complies with REACH requirements.
  • Improves conditions of use and production.
  • Solution builder / integrator turnkey.
  • Our equipment is delivered assembled, ready for operation, it is provided with plate manufacturer EC, technical file and EC Declaration of Conformity.

Data sheet

Height2110 mm
Width600 mm
Depth1880 mm max
Weight313 kg
UseIndustrial use less than 1000 H / year
RateUp to 20 barrels / hour
PackagingDrum and container
Product supplyGravity, pump, pressure
FlowAdvocated 8 m³/h
Sound levelLess than 70 dB at 1m
General constructionPainted steel rust protection
Product circuitStainless steel 316L
Power supply230 V
Total power1 KW
Pneumatic supply6 bars clean and dry / 100L/h
Management height canesManual + spring support
Dive of canePartial diving (420 mm stroke)
Filling modeOn fixed level
Managing multi-level packagingYes with manual settings
Stroke adjuster of caneAdjustable stroke in high and low position
Diameter of the caneDiameter 40 mm default
Device fillingFilling lance D40-C420 stanless steel pneumatic actuator
Management dosage packaging Automatic filling according to a target weight
DocumentationTechnical file including manual handling, mounting and connection, use, maintenance, spare parts list, EC certificate
